A Thermal Annealing Furnace is an advanced heat treatment solution engineered to relieve internal stresses, refine microstructure, and enhance mechanical or electrical properties of materials. Widely used in industries such as semiconductors, metallurgy, glass manufacturing, and research laboratories, this furnace supports high-temperature, uniform, and repeatable thermal processing under controlled environments.
Our Thermal Annealing Furnace series offers high thermal uniformity and precise temperature control for demanding industrial and R&D processes. It is designed for batch or continuous heat treatment of metals, glass, ceramics, and semiconductor substrates. Advanced insulation and control systems ensure maximum energy efficiency and product integrity.
| Temperature Range | Up to 1300°C (Standard range: 400°C–1100°C) |
| Temperature Uniformity | ±3°C or better (Depending on chamber size and design) |
| Heating Method | Electric resistance heating / Infrared (IR) / Optional gas heating |
| Control System | Multi-zone PID temperature controllers with programmable thermal profiles |
| Chamber Volume | From small lab-scale units (~10 liters) to large industrial capacities (>1000 liters) |
| Atmosphere Options | Air, nitrogen, argon, vacuum, or forming gas |
| Cooling System | Natural cooling / Forced air or gas quench (optional) |
| Power Supply | 3-phase AC (220V / 380V / 440V), frequency 50/60Hz |
Multi-zone heating elements and closed-loop feedback ensure excellent thermal accuracy.
Optimized chamber design and insulation materials deliver consistent heat distribution.
Easily upgradeable with options such as rapid cooling modules, gas purging, and data logging.
Use of clean heating elements and high-purity chamber linings suitable for semiconductor-grade processes.
High-quality materials and robust engineering ensure durability and consistent performance over years.
Annealing of silicon wafers, oxide layers, and dielectric films for device fabrication.
Stress-relief and recrystallization of ferrous and non-ferrous metals.
Removing internal tension in precision optical glass and ceramic components.
Post-process heat treatment of printed metal parts to improve mechanical properties.
Controlled thermal testing and materials development under various atmospheric conditions.
Custom chamber sizes & heating zones
Optional cleanroom-compatible designs (Class 100 or higher)
Integrated data acquisition & SCADA systems
Automation features including robotic loading, recipe control, and alarms
Special gas inlet and vacuum ports for controlled environments
Our experts assist in selecting or designing the ideal furnace for your process.
Delivered fully assembled or in modular form for onsite assembly.
Onsite or remote training to ensure safe and optimal use.
24/7 technical assistance, spare parts availability, maintenance contracts.
With decades of experience in thermal systems design, we provide reliable, efficient, and high-precision annealing furnace solutions that meet the highest industry standards. Whether you are scaling up production or refining your R&D capabilities, our furnaces deliver performance you can trust.
