Equipped with high-performance gas burners and automatic control for stable flame and optimal heat transfer.
Advanced chamber design with optional forced convection ensures consistent temperature across the workspace.
Typical max temperatures range from 900°C to 1300°C, suitable for various thermal processing applications.
Rapid heat-up rates reduce cycle times, while gas combustion lowers energy costs versus electric furnaces.
Made from high-grade refractory insulation and stainless steel housing to ensure durability and safety.
Available with programmable PLC systems, digital PID controllers, and optional SCADA integration.
| Model | Max Temp (°C) | Heating Method | Chamber Volume (L) | Fuel Type | Temperature Uniformity | Control System |
| YN-600 | 1100 | Direct gas-fired | 600 | Natural Gas / LPG | ±5°C | PID / PLC |
| YN-1000 | 1200 | Forced convection | 1000 | Natural Gas / LPG | ±3°C | PLC + Touchscreen |
| YN-1500 | 1300 | Radiant tube | 1500 | Natural Gas | ±5°C | PLC + SCADA |
Annealing, normalizing, tempering, hardening
Firing and sintering of ceramic components
Preheating billets, ingots, and molds
Component heat treatment with tight tolerance
Catalyst activation, reaction chamber heating
Preheating and forming
Our Gas Fired Furnaces combine reliable thermal performance with smart automation and long-term durability. Whether you need a compact bench-top unit or a large-scale industrial furnace, we offer tailor-made solutions backed by professional engineering support. Reduce energy consumption, lower emissions, and boost your productivity with our advanced gas heating technology.
