Utilizes the heat of gasification and combustion, achieving fuel efficiency up to 75% compared to direct coal firing.
Generates low-dust, low-sulfur producer gas, improving combustion environment and reducing flue gas pollution.
Designed for uninterrupted coal gas production, suitable for round-the-clock industrial operations.
Reduces fuel cost by utilizing readily available coal, especially in regions where gas or oil is expensive.
Can be integrated with reheating furnaces, annealing furnaces, rotary kilns, glass melting tanks, and other thermal systems.
Optional PLC-based control for gas output regulation, pressure monitoring, and safety interlocks.
| Parameter | Value |
| Fuel Type | Bituminous coal / lignite / anthracite |
| Gas Output | Single-stage: 500–5000 Nm³/h; Double-stage: 1500–12000 Nm³/h |
| Gas Calorific Value | ~1000–1500 kcal/Nm³ |
| Gasification Temperature | 1000–1300 °C |
| Gas Purity | Tar and dust removed via multi-stage filtering |
| Control System | Manual / Semi-automatic / PLC-based automation |
| Cooling & Filtering | Integrated cyclone dust collector, scrubber tower, and gas cooler available |
Reheating furnaces in rolling mills, forging lines, and foundries.
Tunnel kilns and shuttle kilns for bricks, tiles, and ceramics.
Preheating and melting of batch materials in glass tanks.
Used as a reducing atmosphere or as synthesis gas in chemical processes.
Applied in annealing, carburizing, and other thermal processes requiring controlled atmosphere.
Compact, ideal for small-scale gas demand.
Higher efficiency with separate dry and wet gas processing stages.
Stable flame, suited for steady gas flow.
Higher gas calorific value, best for heat-intensive applications.
Units tailored from 500 Nm³/h to over 10,000 Nm³/h based on energy needs.
Designs adapted to local coal types and ash content.
Add-ons for tar removal, dust collection, desulfurization to meet local emission norms.
Full-package solutions including gas pipelines, burners, valves, and control cabinets.
On-site assembly guidance and operation training services available worldwide.
